Starna Cells Optical Glass Fluorometer Cell, 10 mm Path Length
Fluorometer Cell, 10 mm Path Length, 12.5 L x 12.5 W x 45 mm H Exterior, 10 L x 10 mm W Interior, Optical Glass, Rectangular, 3.5 ml Nominal Volume, 4 Polished Windows, 334 to 2500 nm Range, For Fluorometers
- Manufacturer Part No: 3-G-10
- SECO Part No: 3-G-10
- Sold As:
-
Availability:
Login to View Your Price
-
List Price :
Standard rectangular fluorometer cells type 3 are the most popular cells for general fluorescence measurement and they will fit virtually every fluorometer instrument. All four windows and the bottom of the cell are polished and because of the technique used in their construction they remain extremely flat, right to the very edge of the window, allowing them to be used in some laser applications. Each cell is supplied with a PTFE cover. Smaller volume types 9F, 17F & 18F are identical to the type 9 semi-micro, type 17 short-micro and type 18 micro range, except that all cell walls and the base are optically polished.
| Material (ml/min) | : | Optical Glass |
| Shape | : | Rectangular |
| Path Length | : | 10 mm |
| For Use With | : | For Fluorometers |
| Length | : | 12.5 mm Exterior, 10 mm Interior |
| Width | : | 12.5 mm Exterior, 10 mm Interior |
| Exterior Height | : | 45 mm |
| Thickness | : | 1.25 mm |
| Type | : | Standard |
| Range | : | 334 to 2500 nm |
| Nominal Volume | : | 3.5 ml |
| Number Polished Window | : | 4 |
| Cell Top | : | Open |
| Includes | : | With Non-sealing PTFE Cover |
- Physical configuration: Window and base thickness (1.25 mm)
- Primary use: Fluorescence measurement in useable range
- Clear windows: Four, with base polished
- Instrument: Can be used with virtually all fluorometers
- Cell top: Open top, supplied with a non-sealing PTFE cover
