MilliporeSigma Silica Gel 60 TLC Plate, Glass, 20 x 20 cm
TLC Plate, 20 x 20 cm, Glass Backing, Silica Gel 60 Sorbent, 170 to 250 µm Layer Thickness, 480 to 540 m2/g Specific Surface Area, 0.74 to 0.84 ml/g Pore Volume, Fibre Case Packaging Type, with 2.5 x 20 cm Concentrating Zone
- Manufacturer Part No: 1.11845.0001
- SECO Part No: 17-1486-60
- Sold As:
-
Availability:
Login to View Your Price
-
List Price :
These plates allow users to quickly and easily apply any kind of sample, even large volumes of diluted samples. Our concentrating zone plates are based on different adsorption properties of two adsorbents. The first is a large pore concentrating adsorbent where the samples are applied, the second is a selective layer for separation. Regardless of the spots' shape, size, or position, the sample always concentrates as a narrow band where the two adsorbents overlap and where the separation starts. These plates allow users to quickly and easily apply any kind of sample, even large volumes of diluted samples.
| Packaging Type | : | Fibre Case |
| Sheet Type | : | TLC Plate |
| Number of Sheets | : | 25 |
| Sheet Dimension | : | 20 x 20 cm |
| Layer Thickness | : | 170 to 250 µm |
| Backing Material | : | Glass |
| Deviation of Layer Thickness per Plate | : | =50 µm |
| Specific Surface Area | : | 480 to 540 m2/g |
| Pore Volume | : | 0.74 to 0.84 ml/g |
| D 50 Particle Size | : | 10 to 12 µm |
| Sorbent | : | Silica Gel 60 |
| Pore Size | : | 60 µm |
| Concentrating Zone Size | : | 2.5 x 20 cm |
| Concentrating Zone Layer Thickness | : | 90 to 130 µm |
| Concentration Zone Fluctuation Thickness | : | =35 µm |
