DWK Life Sciences (Kimble) 926300-0024
Share
  1. pin-int
Email Print

DWK Life Sciences (Kimble) Two-piece Vacuum Trap, 400 H x 160 mm W

Vacuum Trap, 400 H x 160 mm W, Plain, Borosilicate Glass, 250 H x 48 mm OD Body Below Joint, 20 mm OD Inner Tubing, 45/50 Standard Taper Joint, With 180° Connections, Two-piece Construction Allows Removal of Condensate

  • Manufacturer Part No: 926300-0024
  • SECO Part No: DWK-926300-0024
  • Sold As:
  • Availability: loading
Height : 400 mm
Body Height : 250 mm Below Joint
Body Diameter : 48 mm OD Below Joint
Inner Tubing Diameter : 20 mm OD
Material (ml/min) : Borosilicate Glass
Width : 160 mm
Standard Taper Joint : 45/50
  • This trap protects the mechanical pump from attack by corrosive vapors which can be condensed by using liquid nitrogen or dry ice/slurry mixtures
  • Outlets are 180° apart for easy installation into a variety of vacuum systems
  • Two-piece construction allows removal of condensate
  • Connectors of 926035 series are barbed and fit 0.5" ID flexible tubing
  • Connectors of 926300 series are plain
  • Manufactured from 33 expansion, low extractable borosilicate glass conforming to USP type I and ASTM E438, type I, class A requirements
