A&D Weighing EK-1200i
Share
  1. pin-int
Email Print

A&D Weighing Everest EW/EK Series Single Weighing Range Compact Balance, 1200 g, 0.1 g Resolution

Compact Balance, 1200 g, 53 H x 190 W x 218 mm D, Rugged Metal, 133 x 170 mm Stainless Steel Pan, 0.1 g Readability, 0.1 mg Repeatability, ±0.1 g Linearity, 2 sec Stabilization Time, 7 Segment LCD Display with Backlight, External Calibration

  • Manufacturer Part No: EK-1200i
  • SECO Part No: 16-2350-14
  • Sold As:
  • Availability: loading

Versatile weighing ranges and robust design. For years the EK/EW models have been popular compact balances for a wide variety of applications. Now the new Everest compact balances have been designed to carry on their tradition with enhanced capacities and resolutions, and EW-i models come with attractive triple ranges of weighing. New electronics, wider selection of capacities and resolutions, and remote-zeroing have been included in a low-profile rugged housing. All feature RS-232C standard and are designed to meet weights and measures regulations for various countries.

Capacity : 1200 g
Dimension : 53 H x 190 W x 218 mm D
Material (ml/min) : Rugged Metal
Platform Material : Stainless Steel
Platform Dimension : 133 x 170 mm
Resolution : 0.1 g
Repeatability : 0.1 mg
Linearity : ±0.1 g
Calibration Type : External
Stabilization Time : 2 sec
Weighing Unit : g, oz, lb, ozt, ct, mom, dwt, grain, tl, pcs, %
Sensitivity Drift : ±20 ppm/°C
Display Type : 7 Segment LCD with Backlight
Display Refresh : 10 times/sec
Maximum Count : 12000 pcs
Minimum Unit Weight : 0.1 g
Number of Samples : 5, 10, 25, 50 or 100 pcs
Operating Condition : -10 to 40°C Temperature, Less Than 85% Relative Humidity (Non-condensing)
Interface : RS-232C
Weight : 1.5 kg
Power Requirement : AC Adapter or Battery Powered
Legal For Trade : NTEP
Connectivity : RS-232C Interface
Minimum % Display : 0.1%
Minimum 100% Weight : 10 g
Model : Everest EW/EK Series
Battery Type : Ni-MH Battery
Battery Life : 9 Hours
Calibration Mass : 1200 g
  • Compact rugged design and reliable SG weighing technology
  • Versatile single and triple weighing ranges to fit your counting, percent and compartor applications
  • NTEP approved and intrinsically safe explosion proof versions
  • Single (EK-i) and tripe weighing (EW-i) ranges make it a flexible workhorse
  • Low profile rugged metal housing construction allows for reliable results every time
  • Small footprint compact design is a space saver on any work bench or production environment
  • Battery operation (approx. 250 hours) for high portability, requiring no power supply from a safe area via a safety barrier (EP)
  • Large LCD display (16 mm height) with back light - easy to read even at a wide viewing angle or dark environment
  • Easy to clean chemical resistant stainless steal floors, pans (SUS304) and sealed key panel protection against dust and spills
  • 5 Button navigation is simple to turn on, re-zero/tare, print, access weighing modes and enter sample counts
  • Meet all your application demands with comparator (HI, OK, LOW), percent, counting with ACAI
  • Over protection will save you time and worry concerning overloads errors or operation damage
  • Capture balance ID with GLP printout
  • Control zero, mode selections, and data output with standard RS-232C
  • Data memory function (up to 200 pts)
  • Auto power off
  • Full digital calibration
  • 5 Year US warranty
  • Approved by GLP, GMP, ISO compliant
